Monday, 10 December 2018

Disabling Spring Security if you don't require it

When using Spring Cloud Services Starter Config Client dependency for example Spring Security will also be included (Config servers will be protected by OAuth2). As a result this will also enable basic authentication to all our service endpoints on your application which may not be the desired result here if your just building a demo for example

Add the following to conditionally disable security in your Spring Boot main class


package com.example.employeeservice;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

import org.springframework.cloud.client.discovery.EnableDiscoveryClient;
import org.springframework.context.annotation.Configuration;
import org.springframework.security.config.annotation.web.builders.WebSecurity;
import org.springframework.security.config.annotation.web.configuration.WebSecurityConfigurerAdapter;

@SpringBootApplication
@EnableDiscoveryClient
public class EmployeeServiceApplication {

    public static void main(String[] args) {
        SpringApplication.run(EmployeeServiceApplication.class, args);
    }

    @Configuration
    static class ApplicationSecurity extends WebSecurityConfigurerAdapter {

        @Override
        public void configure(WebSecurity web) throws Exception {
            web
                    .ignoring()
                    .antMatchers("/**");
        }
    }
}

Monday, 8 October 2018

Spring Cloud GCP using Spring Data JPA with MySQL 2nd Gen 5.7

Spring Cloud GCP adds integrations with Spring JDBC so you can run your MySQL or PostgreSQL databases in Google Cloud SQL using Spring JDBC, or other libraries that depend on it like Spring Data JPA. Here is an example of how using Spring Data JPA with "Spring Cloud GCP"

1. First we need a MySQL 2nd Gen 5.7 database to exist in our GCP account which I have previously created as shown below




2. Create a new project using Spring Initializer or how ever you like to create it BUT ensure you have the following dependencies in place. Here is an example of what my pom.xml looks like. In short add the following maven dependencies as per the image below



pom.xml


<parent>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-parent</artifactId>
    <version>2.0.5.RELEASE</version>
    <relativePath/> <!-- lookup parent from repository -->
</parent>

<properties>
    <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
    <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>
    <java.version>1.8</java.version>
    <spring-cloud-gcp.version>1.0.0.RELEASE</spring-cloud-gcp.version>
    <spring-cloud.version>Finchley.SR1</spring-cloud.version>
</properties>

<dependencies>
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-data-jpa</artifactId>
    </dependency>
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-data-rest</artifactId>
    </dependency>
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-thymeleaf</artifactId>
    </dependency>
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-web</artifactId>
    </dependency>
    <dependency>
        <groupId>org.springframework.cloud</groupId>
        <artifactId>spring-cloud-gcp-starter</artifactId>
    </dependency>
    <dependency>
        <groupId>org.springframework.cloud</groupId>
        <artifactId>spring-cloud-gcp-starter-sql-mysql</artifactId>
    </dependency>
    <dependency>
        <groupId>mysql</groupId>
        <artifactId>mysql-connector-java</artifactId>
        <scope>runtime</scope>
    </dependency>
    <dependency>
        <groupId>org.projectlombok</groupId>
        <artifactId>lombok</artifactId>
        <optional>true</optional>
    </dependency>
</dependencies>


...

<dependencyManagement>
    <dependencies>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-dependencies</artifactId>
            <version>${spring-cloud.version}</version>
            <type>pom</type>
            <scope>import</scope>
        </dependency>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-gcp-dependencies</artifactId>
            <version>${spring-cloud-gcp.version}</version>
            <type>pom</type>
            <scope>import</scope>
        </dependency>
    </dependencies>
</dependencyManagement>

3. Let's start by creating a basic Employee entity as shown below

Employee.java

package pas.apj.pa.sb.gcp;

import lombok.AllArgsConstructor;
import lombok.Data;
import lombok.NoArgsConstructor;

import javax.persistence.*;

@Entity
@NoArgsConstructor
@AllArgsConstructor
@Data
@Table (name = "employee")
public class Employee {

    @Id
    @GeneratedValue (strategy = GenerationType.AUTO)
    private Long id;

    private String name;

}

4. Let's now add a Rest JpaRepository for our Entity

EmployeeRepository.java

package pas.apj.pa.sb.gcp;

import org.springframework.data.jpa.repository.JpaRepository;

public interface EmployeeRepository extends JpaRepository <Employee, Long> {
}
5. Let's create a basic RestController to show all our Employee entities

EmployeeRest.java

package pas.apj.pa.sb.gcp;

import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

import java.util.List;

@RestController
public class EmployeeRest {

    private EmployeeRepository employeeRepository;

    public EmployeeRest(EmployeeRepository employeeRepository) {
        this.employeeRepository = employeeRepository;
    }

    @RequestMapping("/emps-rest")
    public List<Employee> getAllemps()
    {
        return employeeRepository.findAll();
    }
}

6. Let's create an ApplicationRunner to show our list of Employees as the applications starts up

EmployeeRunner.java

package pas.apj.pa.sb.gcp;

import org.springframework.boot.ApplicationArguments;
import org.springframework.boot.ApplicationRunner;
import org.springframework.stereotype.Component;

@Component
public class EmployeeRunner implements  ApplicationRunner {

    private EmployeeRepository employeeRepository;

    public EmployeeRunner(EmployeeRepository employeeRepository) {
        this.employeeRepository = employeeRepository;
    }

    @Override
    public void run(ApplicationArguments args) throws Exception {
        employeeRepository.findAll().forEach(System.out::println);
    }
}
7. Add a data.sql file to create some records in the database at application startup

data.sql

insert into employee (name) values ('pas');
insert into employee (name) values ('lucia');
insert into employee (name) values ('lucas');
insert into employee (name) values ('siena');

8. Finally our "application.yml" file will need to be able to be able to connect to our MySQL instance running in GCP as well as set some properties for JPA as shown below

spring:
  jpa:
    hibernate:
      ddl-auto: create-drop
      use-new-id-generator-mappings: false
    properties:
      hibernate:
        dialect: org.hibernate.dialect.MariaDB53Dialect
  cloud:
    gcp:
      sql:
        instance-connection-name: fe-papicella:australia-southeast1:apples-mysql-1
        database-name: employees
  datasource:
    initialization-mode: always
    hikari:
      maximum-pool-size: 1


A couple of things in here which are important.

- Set the Hibernate property "dialect: org.hibernate.dialect.MariaDB53Dialect" otherwise without this when hibernate creates tables for your entities you will  run into this error as Cloud SQL database tables are created using the InnoDB storage engine.

ERROR 3161 (HY000): Storage engine MyISAM is disabled (Table creation is disallowed).

- For a demo I don't need multiple DB connections so I set the datasource "maximum-pool-size" to 1

- Notice how I set the "instance-connection-name" and "database-name" which is vital for Spring Cloud SQL to establish database connections

8. Now we need to make sure we have a database called "employees" as per our "application.yml" setting.


9. Now let's run our Spring Boot Application and verify this working showing some output from the logs

- Connection being established

2018-10-08 10:54:37.333  INFO 89922 --- [           main] c.google.cloud.sql.mysql.SocketFactory   : Connecting to Cloud SQL instance [fe-papicella:australia-southeast1:apples-mysql-1] via ssl socket.
2018-10-08 10:54:37.335  INFO 89922 --- [           main] c.g.cloud.sql.core.SslSocketFactory      : First Cloud SQL connection, generating RSA key pair.
2018-10-08 10:54:38.685  INFO 89922 --- [           main] c.g.cloud.sql.core.SslSocketFactory      : Obtaining ephemeral certificate for Cloud SQL instance [fe-papicella:australia-southeast1:apples-mysql-1].
2018-10-08 10:54:40.132  INFO 89922 --- [           main] c.g.cloud.sql.core.SslSocketFactory      : Connecting to Cloud SQL instance [fe-papicella:australia-southeast1:apples-mysql-1] on IP [35.197.180.223].
2018-10-08 10:54:40.748  INFO 89922 --- [           main] com.zaxxer.hikari.HikariDataSource       : HikariPool-1 - Start completed.

- Showing the 4 Employee records

Employee(id=1, name=pas)
Employee(id=2, name=lucia)
Employee(id=3, name=lucas)
Employee(id=4, name=siena)

10. Finally let's make RESTful call as we defined above using HTTPie as follows

pasapicella@pas-macbook:~$ http :8080/emps-rest
HTTP/1.1 200
Content-Type: application/json;charset=UTF-8
Date: Mon, 08 Oct 2018 00:01:42 GMT
Transfer-Encoding: chunked

[
    {
        "id": 1,
        "name": "pas"
    },
    {
        "id": 2,
        "name": "lucia"
    },
    {
        "id": 3,
        "name": "lucas"
    },
    {
        "id": 4,
        "name": "siena"
    }
]

More Information

Spring Cloud GCP
https://cloud.spring.io/spring-cloud-gcp/

Spring Cloud GCP SQL demo (This one is using Spring JDBC)
https://github.com/spring-cloud/spring-cloud-gcp/tree/master/spring-cloud-gcp-samples/spring-cloud-gcp-sql-sample

Monday, 17 September 2018

PKS - What happens when we create a new namespace with NSX-T

I previously blogged about the integration between PKS and NSX-T on this post

http://theblasfrompas.blogspot.com/2018/09/pivotal-container-service-pks-with-nsx.html

On this post lets show the impact of what occurs within NSX-T when we create a new Namespace in our K8s cluster.

1. List the K8s clusters with have available

pasapicella@pas-macbook:~/pivotal/PCF/APJ/PEZ-HaaS/haas-148$ pks clusters

Name    Plan Name  UUID                                  Status     Action
apples  small      d9f258e3-247c-4b4c-9055-629871be896c  succeeded  UPDATE


2. Fetch the cluster config for our cluster into our local Kubectl config

pasapicella@pas-macbook:~/pivotal/PCF/APJ/PEZ-HaaS/haas-148$ pks get-credentials apples

Fetching credentials for cluster apples.
Context set for cluster apples.

You can now switch between clusters by using:
$kubectl config use-context

3. Create a new Namespace for the K8s cluster as shown below

pasapicella@pas-macbook:~/pivotal/PCF/APJ/PEZ-HaaS/haas-148$ kubectl create namespace production
namespace "production" created

4. View the Namespaces in the K8s cluster

pasapicella@pas-macbook:~/pivotal/PCF/APJ/PEZ-HaaS/haas-148$ kubectl get ns
NAME          STATUS    AGE
default       Active    12d
kube-public   Active    12d
kube-system   Active    12d
production    Active    9s

Using NSX-T manager the first thing you will see is a new Tier 1 router created for the K8s namespace "production"



Lets view it's configuration via the "Overview" screen


Finally lets see the default "Logical Routes" as shown below



When we push workloads to the "Production" namespace it's this configuration which was dynamically created which we will get out of the box allowing us to expose a "LoadBalancer" service as required across the Pods deployed within the Namspace

Wednesday, 5 September 2018

Pivotal Container Service (PKS) with NSX-T on vSphere

It taken some time but now I officially was able to test PKS with NSX-T rather then using Flannel.

While there is a bit of initial setup to install NSX-T and PKS and then ensure PKS networking is NSX-T, the ease of rolling out multiple Kubernetes clusters with unique networking is greatly simplified by NSX-T. Here I am going to show what happens after pushing a workload to my PKS K8s cluster

First Before we can do anything we need the following...

Pre Steps

1. Ensure you have NSX-T setup and a dashboard UI as follows


2. Ensure you have PKS installed in this example I have it installed on vSphere which at the time of this blog is the only supported / applicable version we can use for NSX-T



PKS tile would need to ensure it's setup to use NSX-T which is done on this page of the tile configuration



3. You can see from the NSX-T manager UI we have a Load Balancers setup as shown below. Navigate to "Load Balancing -> Load Balancers"



And this Load Balancer is backed by few "Virtual Servers", one for http (port 80) and the other for https (port 443), which can be seen when you select the Virtual Servers link


From here we have logical switches created for each of the Kubernetes namespaces. We see two for our load balancer, and the other 3 are for the 3 K8s namespaces which are (default, kube-public, kube-system)


Here is how we verify the namespaces we have in our K8s cluster

pasapicella@pas-macbook:~/pivotal $ kubectl get ns
NAME          STATUS    AGE
default       Active    5h
kube-public   Active    5h
kube-system   Active    5h

All of the logical switches are connected to the T0 Logical Switch by a set of T1 Logical Routers


For these to be accessible, they are linked to the T0 Logical Router via a set of router ports



Now lets push a basic K8s workload and see what NSX-T and PKS give us out of the box...

Steps

Lets create our K8s cluster using the PKS CLI. You will need a PKS CLI user which can be created following this doc

https://docs.pivotal.io/runtimes/pks/1-1/manage-users.html

1. Login using the PKS CLI as follows

$ pks login -k -a api.pks.haas-148.pez.pivotal.io -u pas -p ****

2. Create a cluster as shown below

$ pks create-cluster apples --external-hostname apples.haas-148.pez.pivotal.io --plan small

Name:                     apples
Plan Name:                small
UUID:                     d9f258e3-247c-4b4c-9055-629871be896c
Last Action:              CREATE
Last Action State:        in progress
Last Action Description:  Creating cluster
Kubernetes Master Host:   apples.haas-148.pez.pivotal.io
Kubernetes Master Port:   8443
Worker Instances:         3
Kubernetes Master IP(s):  In Progress

3. Wait for the cluster to have created as follows

$ pks cluster apples

Name:                     apples
Plan Name:                small
UUID:                     d9f258e3-247c-4b4c-9055-629871be896c
Last Action:              CREATE
Last Action State:        succeeded
Last Action Description:  Instance provisioning completed
Kubernetes Master Host:   apples.haas-148.pez.pivotal.io
Kubernetes Master Port:   8443
Worker Instances:         3
Kubernetes Master IP(s):  10.1.1.10

The PKS CLI is basically telling BOSH to go ahead an based on the small plan create me a fully functional/working K8's cluster from VM's to all the processes that go along with it and when it's up keep it up and running for me in the event of failure.

His an example of the one of the WORKER VM's of the cluster shown in vSphere Web Client



4. Using the following YAML file as follows lets push that workload to our K8s cluster

apiVersion: v1
kind: Service
metadata:
  labels:
    app: fortune-service
    deployment: pks-workshop
  name: fortune-service
spec:
  ports:
  - port: 80
    name: ui
  - port: 9080
    name: backend
  - port: 6379
    name: redis
  type: LoadBalancer
  selector:
    app: fortune
---
apiVersion: v1
kind: Pod
metadata:
  labels:
    app: fortune
    deployment: pks-workshop
  name: fortune
spec:
  containers:
  - image: azwickey/fortune-ui:latest
    name: fortune-ui
    ports:
    - containerPort: 80
      protocol: TCP
  - image: azwickey/fortune-backend-jee:latest
    name: fortune-backend
    ports:
    - containerPort: 9080
      protocol: TCP
  - image: redis
    name: redis
    ports:
    - containerPort: 6379
      protocol: TCP

5. Push the workload as follows once the above YAML is saved to a file

$ kubectl create -f fortune-teller.yml
service "fortune-service" created
pod "fortune" created

6. Verify the PODS are running as follows

$ kubectl get all
NAME         READY     STATUS    RESTARTS   AGE
po/fortune   3/3       Running   0          35s

NAME                  TYPE           CLUSTER-IP       EXTERNAL-IP    PORT(S)                                      AGE
svc/fortune-service   LoadBalancer   10.100.200.232   10.195.3.134   80:30591/TCP,9080:32487/TCP,6379:32360/TCP   36s
svc/kubernetes        ClusterIP      10.100.200.1              443/TCP                                      5h

Great so now lets head back to our NSX-T manager UI and see what has been created. From the above output you can see a LB service is created and external IP address assigned

7. First thing you will notice is in "Virtual Servers" we have some new entries for each of our containers as shown below


and ...


Finally the LB we previously had in place shows our "Virtual Servers" added to it's config and routable



More Information

Pivotal Container Service
https://docs.pivotal.io/runtimes/pks/1-1/

VMware NSX-T
https://docs.vmware.com/en/VMware-NSX-T/index.html

Monday, 20 August 2018

PCF Platform Automation with Concourse (PCF Pipelines)

Previously I blogged about using "Bubble" or bosh-bootloader as per the post below.

http://theblasfrompas.blogspot.com/2018/08/bosh-bootloader-or-bubble-as-pronounced.html

... and from there setting up Concourse

http://theblasfrompas.blogspot.com/2018/08/deploying-concourse-using-my-bubble.html

.. of course this was created so I can now use the PCF Pipelines to deploy Pivotal Cloud Foundry's Pivotal Application Service (PAS). At a high level this is how to achieve this with some screen shots on the end result

Steps

1. To get started you would use this link as follows. In my example I was deploying PCF to AWS

https://github.com/pivotal-cf/pcf-pipelines/tree/master/install-pcf

AWS Install Pipeline

https://github.com/pivotal-cf/pcf-pipelines/tree/master/install-pcf/aws

2. Create a versioned bucket for holding terraform state. on AWS that will look as follows


3. Unless you ensure AWS pre-reqs are meet you won't be able to install PCF so this link highlights all that you will need for installing PCF on AWS such as key pairs, limits, etc

https://docs.pivotal.io/pivotalcf/2-1/customizing/aws.html

4. Create a public DNS zone, get its zone ID we will need that when we setup the pipeline shortly. I also created a self signed public certificate used for my DNS as part of the setup which is required as well.





5. At this point we can download the PCF Pipelines from network.pivotal.io or you can use the link as follows

https://network.pivotal.io/products/pcf-automation/



6. Once you have unzipped the file you would then change to the directory for the write IaaS in my case "aws"

$ cd pcf-pipelines/install-pcf/aws


7. Change all of the CHANGEME values in params.yml with real values for your AWS env. This file is documented so you are clear with what you need to add and where. Most of the values are defaults of course.

8. Login to concourse using the "fly" command line

$ fly --target pcfconcourse login  --concourse-url https://bosh-director-aws-concourse-lb-f827ef220d02270c.elb.ap-southeast-2.amazonaws.com -k

9. Add pipeline

$ fly -t pcfconcourse set-pipeline -p deploy-pcf -c pipeline.yml -l params.yml

10. Unpause pipeline

$ fly -t pcfconcourse unpause-pipeline -p deploy-pcf

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines/pcf-pipelines/install-pcf/aws$ fly -t pcfconcourse pipelines
name        paused  public
deploy-pcf  no      no

11. The pipeline on concourse will look as follows



12. Now to execute the pipeline you have to manually run 2 tasks

- Run bootstrap-terraform-state job manually




- Run create-infrastructure manually



At this point the pipeline will kick of automatically. If you need to run-run due to an issue you can manually kick off the task after you fix what you need to fix. The “wipe-env” task will take everything for PAS down and terraform removes all IaaS config as well.

While running each task current state is shown as per the image below


If successful your AWS account will the PCF VM's created for example


Verify that PCF installed is best done using Pivotal Operations Manager as shown below



More Information

https://network.pivotal.io/products/pcf-automation/


Saturday, 18 August 2018

Deploying concourse using my "Bubble" created Bosh director

Previously I blogged about using "Bubble" or bosh-bootloader as per the post below.

http://theblasfrompas.blogspot.com/2018/08/bosh-bootloader-or-bubble-as-pronounced.html

Now with bosh director deployed it's time to deploy concourse itself. The process is very straight forward as per the steps below

1. First let's clone the bosh concourse deployment using the GitHub project as follows



2.  Target bosh director and login, must set ENV variables to connect to AWS bosh correctly using "eval" as we did in the previous post. This will set all the ENV variables we need

$ eval "$(bbl print-env -s state)"
$ bosh alias-env aws-env
$ bosh -e aws-env log-in

3. At this point we need to set the external URL which is essentially the load balancer we created when we deployed Bosh Director in the previous post. To get that value run a command as follows where we deployed bosh director from as shown below

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ bbl lbs -s state
Concourse LB: bosh-director-aws-concourse-lb [bosh-director-aws-concourse-lb-f827ef220d02270c.elb.ap-southeast-2.amazonaws.com]

4. Now lets set that ENV variable as shown below

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ export external_url=https://bosh-director-aws-concourse-lb-f827ef220d02270c.elb.ap-southeast-2.amazonaws.com

5. Now from the cloned bosh concourse directory change to the directory "concourse-bosh-deployment/cluster" as shown below

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ cd concourse-bosh-deployment/cluster

6. Upload stemcell as follows

$ bosh upload-stemcell light-bosh-stemcell-3363.69-aws-xen-hvm-ubuntu-trusty-go_agent.tgz

Verify:

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ bosh -e aws-bosh stemcells
Using environment 'https://10.0.0.6:25555' as client 'admin'

Name                                     Version  OS             CPI  CID
bosh-aws-xen-hvm-ubuntu-trusty-go_agent  3363.69  ubuntu-trusty  -    ami-0812e8018333d59a6

(*) Currently deployed

1 stemcells

Succeeded

7. Now lets deploy concourse as shown below with a command as follows. Make sure you set a password as per "atc_basic_auth.password"

$ bosh deploy -d concourse concourse.yml   -l ../versions.yml   --vars-store cluster-creds.yml   -o operations/basic-auth.yml   -o operations/privileged-http.yml   -o operations/privileged-https.yml   -o operations/tls.yml   -o operations/tls-vars.yml   -o operations/web-network-extension.yml   --var network_name=default   --var external_url=$external_url   --var web_vm_type=default   --var db_vm_type=default   --var db_persistent_disk_type=10GB   --var worker_vm_type=default   --var deployment_name=concourse   --var web_network_name=private   --var web_network_vm_extension=lb  --var atc_basic_auth.username=admin --var atc_basic_auth.password=..... --var worker_ephemeral_disk=500GB_ephemeral_disk -o operations/worker-ephemeral-disk.yml

8. Once deployed verify the deployment and VM's created as follows

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ bosh -e aws-env deployments
Using environment 'https://10.0.0.6:25555' as client 'admin'

Name       Release(s)          Stemcell(s)                                      Team(s)
concourse  concourse/3.13.0    bosh-aws-xen-hvm-ubuntu-trusty-go_agent/3363.69  -
           garden-runc/1.13.1
           postgres/28

1 deployments

Succeeded
pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ bosh -e aws-env vms
Using environment 'https://10.0.0.6:25555' as client 'admin'

Task 32. Done

Deployment 'concourse'

Instance                                     Process State  AZ  IPs        VM CID               VM Type  Active
db/db78de7f-55c5-42f5-bf9d-20b4ef0fd331      running        z1  10.0.16.5  i-04904fbdd1c7e829f  default  true
web/767b14c8-8fd3-46f0-b74f-0dca2c3b9572     running        z1  10.0.16.4  i-0e5f1275f635bd49d  default  true
worker/cde3ae19-5dbc-4c39-854d-842bbbfbe5cd  running        z1  10.0.16.6  i-0bd44407ec0bd1d8a  default  true

3 vms

Succeeded

9. Navigate to the LB url we used above to access concourse UI using the username/password you set as per the deployment

https://bosh-director-aws-concourse-lb-f827ef220d02270c.elb.ap-southeast-2.amazonaws.com/


10. Finally we can see of Bosh Director and Concourse deployment VM's on our AWS instance EC2 page as follows



More Information

Wednesday, 15 August 2018

bosh-bootloader or "Bubble" as pronounced and how to get started

I decided to try out installing bosh using the bosh-bootloader CLI today. bbl currently supports AWS, GCP, Microsoft Azure, Openstack and vSphere. In this example I started with AWS but it won't be long until try this on GCP

It's worth noting that this can all be done remotely from your laptop once you give BBL the access it needs for the cloud environment.

Steps

1. First your going to need the bosh v2 CLI which you can install here

  https://bosh.io/docs/cli-v2/

Verify:

pasapicella@pas-macbook:~$ bosh -version
version 5.0.1-2432e5e9-2018-07-18T21:41:03Z

Succeeded

2. Second you will need Terrform having a Mac I use brew

$ brew install terrafrom

Verify:

pasapicella@pas-macbook:~$ terraform version
Terraform v0.11.7


3. Now we need to install BBL which is done as follows on a Mac. I also show how to install bosh CLI as well if you missed step 1

$ brew tap cloudfoundry/tap
$ brew install bosh-cli
$ brew install bbl

Further instructions on this link

https://github.com/cloudfoundry/bosh-bootloader

4. At this point your ready to deploy BOSH the instructions for AWS are here

https://github.com/cloudfoundry/bosh-bootloader/blob/master/docs/getting-started-aws.md

Pretty straight forward but here is what I did at this point

5. In order for bbl to interact with AWS, an IAM user must be created. This user will be issuing API requests to create the infrastructure such as EC2 instances, load balancers, subnets, etc.

The user must have the following policy which I just copy into my clipboard to use later:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Sid": "VisualEditor0",
            "Effect": "Allow",
            "Action": [
                "logs:*",
                "elasticloadbalancing:*",
                "cloudformation:*",
                "iam:*",
                "kms:*",
                "route53:*",
                "ec2:*"
            ],
            "Resource": "*"
        }
    ]
}


$ aws iam create-user --user-name "bbl-user”

This next command requires you to copy the policy JSON above

$ aws iam put-user-policy --user-name "bbl-user" --policy-name "bbl-policy" --policy-document "$(pbpaste)"

$ aws iam create-access-key --user-name "bbl-user"

You will get a JSON response at this point as follows. Save file created here as it’s used next few steps

{
    "AccessKey": {
        "UserName": "bbl-user",
        "Status": "Active",
        "CreateDate": "2018-08-07T03:30:39.993Z",
        "SecretAccessKey": ".....",
        "AccessKeyId": "........"
    }
}

In the next step BBL will use these commands to create infrastructure on AWS.

6. Now we can pave the infrastructure, Create a Jumpbox, and Create a BOSH Director as well as a LB which I need as I plan to deploy concourse using BOSH.

$ bbl up --aws-access-key-id ..... --aws-secret-access-key ... --aws-region ap-southeast-2 --lb-type concourse --name bosh-director -d -s state --iaas aws

The process takes around 5-8 minutes.

The bbl state directory contains all of the files that were used to create your bosh director. This should be checked in to version control, so that you have all the information necessary to later destroy or update this environment at a later date.

7.  Finally we target the the bosh director as follows. Keep in mind everything we need is stored in the "state" directory as per above

$ eval "$(bbl print-env -s state)"

8. This will set various ENV variables which the bosh CLI will then use to target the bosh director.  Now we need to just prepare ourselves to actually log in. I use a script as follows

target-bosh.sh

bbl director-ca-cert -s state > bosh.crt
export BOSH_CA_CERT=bosh.crt

export BOSH_ENVIRONMENT=$(bbl director-address -s state)

echo ""
echo "Username: $(bbl director-username -s state)"
echo "Password: $(bbl director-password -s state)"
echo ""
echo "Log in using -> bosh log-in"
echo ""

bosh alias-env aws-env

echo "ENV set to -> aws-env"
echo ""

Output When run with password omitted ->

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ ./target-bosh.sh

Username: admin
Password: ......

Log in using -> bosh log-in

Using environment 'https://10.0.0.6:25555' as client 'admin'

Name      bosh-bosh-director-aws
UUID      3ade0d28-77e6-4b5b-9be7-323a813ac87c
Version   266.4.0 (00000000)
CPI       aws_cpi
Features  compiled_package_cache: disabled
          config_server: enabled
          dns: disabled
          snapshots: disabled
User      admin

Succeeded
ENV set to -> aws-env

9. Finally lets log-in as follows

$ bosh -e aws-env log-in

Output ->

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ bosh -e aws-env log-in
Successfully authenticated with UAA

Succeeded

10. Last but not least lets see what VM's bosh has under management. These VM's are for my concourse I installed. If you would like to install concourse use this link - https://github.com/cloudfoundry/bosh-bootloader/blob/master/docs/concourse.md

pasapicella@pas-macbook:~/pivotal/aws/pcf-pipelines$ bosh -e aws-env vms
Using environment 'https://10.0.0.6:25555' as client 'admin'

Task 20. Done

Deployment 'concourse'

Instance                                     Process State  AZ  IPs        VM CID               VM Type  Active
db/ec8aa978-1ec5-4402-9835-9a1cbce9c1e5      running        z1  10.0.16.5  i-0d33949ece572beeb  default  true
web/686546be-09d1-43ec-bbb7-d96bb5edc3df     running        z1  10.0.16.4  i-03af52f574399af28  default  true
worker/679be815-6250-477c-899c-b962076f26f5  running        z1  10.0.16.6  i-0efac99165e12f2e6  default  true

3 vms

Succeeded

More Information

https://github.com/cloudfoundry/bosh-bootloader/blob/master/docs/getting-started-aws.md

https://github.com/cloudfoundry/bosh-bootloader/blob/master/docs/howto-target-bosh-director.md


Wednesday, 20 June 2018

Using CFDOT (CF Diego Operator Toolkit) on Pivotal Cloud Foundry

I decided to use CFDOT (CF Diego Operator Toolkit) on my PCF 2.1 vSphere ENV today. Setting it up isn't required as it's installed out of the box on Bosh Managed Diego Cell as shown below. It gives nice detailed information around Cell Capacity and other useful metrics.

1. SSH into Ops Manager VM

pasapicella@pas-macbook:~/pivotal/PCF/APJ/PEZ-HaaS/haas-165$ ssh ubuntu@opsmgr.haas-165.mydns.com
Unauthorized use is strictly prohibited. All access and activity
is subject to logging and monitoring.
ubuntu@opsmgr.haas-165.mydns.com's password:
Welcome to Ubuntu 14.04.5 LTS (GNU/Linux 4.4.0-124-generic x86_64)

 * Documentation:  https://help.ubuntu.com/

...

ubuntu@bosh-stemcell:~$

At this point you will need to log into the Bosh Director as described below


2. Issue a command as follows once logged in to get all VM's. We just need a name of one of the Diego CELL VM's

ubuntu@bosh-stemcell:~$ bosh -e vmware vms --column=Instance --column="Process State"
Using environment '1.1.1.1' as user 'director' (bosh.*.read, openid, bosh.*.admin, bosh.read, bosh.admin)

Task 12086
Task 12087
Task 12086 done

Task 12087 done

Deployment 'cf-edc48fe108f1e5581fba'

Instance                                                            Process State
backup-prepare/eff97a4b-15a2-425c-8333-1dbaaefbb5ff                 running
clock_global/d77c485f-7d7c-43ae-b9de-584411ffa0bd                   running
cloud_controller/874dd06c-b76e-427a-943e-dea66f0345b6               running
cloud_controller/bba1819e-b7f4-4a34-897a-c78f6189667c               running
cloud_controller_worker/803bfb3f-653b-4311-b831-9b76e602714e        running
cloud_controller_worker/f5956edb-9510-4d99-a0f7-8545831b45ec        running
consul_server/3bfdc6bd-2f1d-4607-8564-148fadd4bc3d                  running
consul_server/4927cc4b-4531-429b-b379-83e283b779ba                  running
consul_server/69c1c5ee-8288-49bd-9112-afe05fe536f4                  running
diego_brain/01d3914c-2ab1-4b75-ada7-2267f34faee6                    running
diego_brain/564cf558-c2dc-4045-a4d1-54f633633dd6                    running
diego_brain/a22c2621-4278-4a83-94ee-34287deb9310                    running
diego_cell/7ca12f7d-737f-47fb-a8bc-91d73e4791cf                     running
diego_cell/9452a3b4-d40c-49f1-9dbf-8d74202f7dff                     running
diego_cell/dfc8e214-2e59-4050-9312-1113662ce79f                     running

...

3. SSH into a Bosh managed Diego Cell VM. Use the correct name for one of your Diego Cells and your deployment name for CF itself

ubuntu@bosh-stemcell:~$ bosh -e vmware -d cf-edc48fe108f1e5581fba ssh diego_cell/7ca12f7d-737f-47fb-a8bc-91d73e4791cf
Using environment '1.1.1.1' as user 'director' (bosh.*.read, openid, bosh.*.admin, bosh.read, bosh.admin)

Using deployment 'cf-edc48fe108f1e5581fba'

....

4. Run a command as follows "sudo su -"

diego_cell/7ca12f7d-737f-47fb-a8bc-91d73e4791cf:~$ sudo su -

5. Verify CFDOT CLI is installed using "cfdot"

diego_cell/7ca12f7d-737f-47fb-a8bc-91d73e4791cf:~# cfdot
A command-line tool to interact with a Cloud Foundry Diego deployment

Usage:
  cfdot [command]

Available Commands:
  actual-lrp-groups            List actual LRP groups
  actual-lrp-groups-for-guid   List actual LRP groups for a process guid
  cancel-task                  Cancel task
  cell                         Show the specified cell presence
  cell-state                   Show the specified cell state
  cell-states                  Show cell states for all cells
  cells                        List registered cell presences
  claim-lock                   Claim Locket lock
  claim-presence               Claim Locket presence
  create-desired-lrp           Create a desired LRP
  create-task                  Create a Task
  delete-desired-lrp           Delete a desired LRP
  delete-task                  Delete a Task
  desired-lrp                  Show the specified desired LRP
  desired-lrp-scheduling-infos List desired LRP scheduling infos
  desired-lrps                 List desired LRPs
  domains                      List domains
  help                         Get help on [command]
  locks                        List Locket locks
  lrp-events                   Subscribe to BBS LRP events
  presences                    List Locket presences
  release-lock                 Release Locket lock
  retire-actual-lrp            Retire actual LRP by index and process guid
  set-domain                   Set domain
  task                         Display task
  task-events                  Subscribe to BBS Task events
  tasks                        List tasks in BBS
  update-desired-lrp           Update a desired LRP

Flags:
  -h, --help   help for cfdot

Use "cfdot [command] --help" for more information about a command.

6. Lets see what each Diego CELL has for Capacity as a whole

diego_cell/7ca12f7d-737f-47fb-a8bc-91d73e4791cf:~# cfdot cells | jq -r
{
  "cell_id": "7ca12f7d-737f-47fb-a8bc-91d73e4791cf",
  "rep_address": "http://10.193.229.62:1800",
  "zone": "RP01",
  "capacity": {
    "memory_mb": 16047,
    "disk_mb": 103549,
    "containers": 249
  },
  "rootfs_provider_list": [
    {
      "name": "preloaded",
      "properties": [
        "cflinuxfs2"
      ]
    },
    {
      "name": "preloaded+layer",
      "properties": [
        "cflinuxfs2"
      ]
    },
    {
      "name": "docker"
    }
  ],
  "rep_url": "https://7ca12f7d-737f-47fb-a8bc-91d73e4791cf.cell.service.cf.internal:1801"
}
{
  "cell_id": "9452a3b4-d40c-49f1-9dbf-8d74202f7dff",
  "rep_address": "http://10.193.229.61:1800",
  "zone": "RP01",
  "capacity": {
    "memory_mb": 16047,
    "disk_mb": 103549,
    "containers": 249
  },
  "rootfs_provider_list": [
    {
      "name": "preloaded",
      "properties": [
        "cflinuxfs2"
      ]
    },
    {
      "name": "preloaded+layer",
      "properties": [
        "cflinuxfs2"
      ]
    },
    {
      "name": "docker"
    }
  ],
  "rep_url": "https://9452a3b4-d40c-49f1-9dbf-8d74202f7dff.cell.service.cf.internal:1801"
}
{
  "cell_id": "dfc8e214-2e59-4050-9312-1113662ce79f",
  "rep_address": "http://10.193.229.63:1800",
  "zone": "RP01",
  "capacity": {
    "memory_mb": 16047,
    "disk_mb": 103549,
    "containers": 249
  },
  "rootfs_provider_list": [
    {
      "name": "preloaded",
      "properties": [
        "cflinuxfs2"
      ]
    },
    {
      "name": "preloaded+layer",
      "properties": [
        "cflinuxfs2"
      ]
    },
    {
      "name": "docker"
    }
  ],
  "rep_url": "https://dfc8e214-2e59-4050-9312-1113662ce79f.cell.service.cf.internal:1801"
}

7. Finally lets see what available resources we have on each Diego Cell

diego_cell/7ca12f7d-737f-47fb-a8bc-91d73e4791cf:~# cfdot cell-states | jq '"Cell Id -> \(.cell_id): L -> \(.LRPs | length), Avaliable Resources [MemoryMB] -> \(.AvailableResources.MemoryMB), Avaliable Resources [DiskMB] -> \(.AvailableResources.DiskMB), Avaliable Resources [Containers] -> \(.AvailableResources.Containers)"' -r

Cell Id -> 7ca12f7d-737f-47fb-a8bc-91d73e4791cf: L -> 17, Avaliable Resources [MemoryMB] -> 6843, Avaliable Resources [DiskMB] -> 86141, Avaliable Resources [Containers] -> 232
Cell Id -> 9452a3b4-d40c-49f1-9dbf-8d74202f7dff: L -> 14, Avaliable Resources [MemoryMB] -> 5371, Avaliable Resources [DiskMB] -> 89213, Avaliable Resources [Containers] -> 235
Cell Id -> dfc8e214-2e59-4050-9312-1113662ce79f: L -> 14, Avaliable Resources [MemoryMB] -> 4015, Avaliable Resources [DiskMB] -> 89213, Avaliable Resources [Containers] -> 235

More Information

https://github.com/cloudfoundry/cfdot


Wednesday, 9 May 2018

Deploying a Spring Boot Application on a Pivotal Container Service (PKS) Cluster on GCP

I have been "cf pushing" for as long as I can remember so with Pivotal Container Service (PKS) let's walk through the process of deploying a basic Spring Boot Application with a PKS cluster running on GCP.

Few assumptions:

1. PKS is already installed as shown by my Operations Manager UI below



2. A PKS Cluster already exists as shown by the command below

pasapicella@pas-macbook:~$ pks list-clusters

Name        Plan Name  UUID                                  Status     Action
my-cluster  small      1230fafb-b5a5-4f9f-9327-55f0b8254906  succeeded  CREATE

Example:

We will be using this Spring Boot application at the following GitHub URL

  https://github.com/papicella/springboot-actuator-2-demo


1. In this example my Spring Boot application has what is required within my maven build.xml file to allow me to create a Docker image as shown below

<!-- tag::plugin[] -->
   <plugin>
    <groupId>com.spotify</groupId>
    <artifactId>dockerfile-maven-plugin</artifactId>
    <version>1.3.6</version>
    <configuration>
     <repository>${docker.image.prefix}/${project.artifactId}</repository>
     <buildArgs>
      <JAR_FILE>target/${project.build.finalName}.jar</JAR_FILE>
     </buildArgs>
    </configuration>
   </plugin>
   <!-- end::plugin[] -->

   <plugin>
    <groupId>org.apache.maven.plugins</groupId>
    <artifactId>maven-dependency-plugin</artifactId>
    <executions>
     <execution>
      <id>unpack</id>
      <phase>package</phase>
      <goals>
       <goal>unpack</goal>
      </goals>
      <configuration>
       <artifactItems>
        <artifactItem>
         <groupId>${project.groupId}</groupId>
         <artifactId>${project.artifactId}</artifactId>
         <version>${project.version}</version>
        </artifactItem>
       </artifactItems>
      </configuration>
     </execution>
    </executions>
</plugin>

2. Once a docker image was built I then pushed that to Docker Hub as shown below



3. Now we will need a PKS cluster as shown below before we can continue

pasapicella@pas-macbook:~$ pks cluster my-cluster

Name:                     my-cluster
Plan Name:                small
UUID:                     1230fafb-b5a5-4f9f-9327-55f0b8254906
Last Action:              CREATE
Last Action State:        succeeded
Last Action Description:  Instance provisioning completed
Kubernetes Master Host:   cluster1.pks.pas-apples.online
Kubernetes Master Port:   8443
Worker Instances:         3
Kubernetes Master IP(s):  192.168.20.10

4. Now we want to wire "kubectl" using a command as follows

pasapicella@pas-macbook:~$ pks get-credentials my-cluster

Fetching credentials for cluster my-cluster.
Context set for cluster my-cluster.

You can now switch between clusters by using:
$kubectl config use-context

pasapicella@pas-macbook:~$ kubectl cluster-info
Kubernetes master is running at https://cluster1.pks.pas-apples.online:8443
Heapster is running at https://cluster1.pks.pas-apples.online:8443/api/v1/namespaces/kube-system/services/heapster/proxy
KubeDNS is running at https://cluster1.pks.pas-apples.online:8443/api/v1/namespaces/kube-system/services/kube-dns/proxy
monitoring-influxdb is running at https://cluster1.pks.pas-apples.online:8443/api/v1/namespaces/kube-system/services/monitoring-influxdb/proxy

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

5. Now we are ready to deploy a Spring Boot workload to our cluster. To do that lets download the YAML file below

https://github.com/papicella/springboot-actuator-2-demo/blob/master/lb-withspringboot.yml

Once downloaded create a deployment as follows

$ kubectl create -f lb-withspringboot.yml

pasapicella@pas-macbook:~$ kubectl create -f lb-withspringboot.yml
service "spring-boot-service" created
deployment "spring-boot-deployment" created

6. Now let’s verify our deployment using some kubectl commands as follows

$ kubectl get deployment spring-boot-deployment
$ kubectl get pods
$ kubectl get svc

pasapicella@pas-macbook:~$ kubectl get deployment spring-boot-deployment
NAME                     DESIRED   CURRENT   UP-TO-DATE   AVAILABLE   AGE
spring-boot-deployment   1         1         1            1           1m

pasapicella@pas-macbook:~$ kubectl get pods
NAME                                     READY     STATUS    RESTARTS   AGE
spring-boot-deployment-ccd947455-6clwv   1/1       Running   0          2m

pasapicella@pas-macbook:~$ kubectl get svc
NAME                  TYPE           CLUSTER-IP       EXTERNAL-IP     PORT(S)          AGE
kubernetes            ClusterIP      10.100.200.1               443/TCP          23m
spring-boot-service   LoadBalancer   10.100.200.137   35.197.187.43   8080:31408/TCP   2m

7. Using the external IP Address we got GCP to expose for us we can access our Spring Boot application on port 8080 as shown below using the external IP address. In this example

http://35.197.187.43:8080/



RESTful End Point

pasapicella@pas-macbook:~$ http http://35.197.187.43:8080/employees/1
HTTP/1.1 200
Content-Type: application/hal+json;charset=UTF-8
Date: Wed, 09 May 2018 05:26:19 GMT
Transfer-Encoding: chunked

{
    "_links": {
        "employee": {
            "href": "http://35.197.187.43:8080/employees/1"
        },
        "self": {
            "href": "http://35.197.187.43:8080/employees/1"
        }
    },
    "name": "pas"
}

More Information

Using PKS
https://docs.pivotal.io/runtimes/pks/1-0/using.html
